Kellys Bicycles (Slovakia) - Press Release: Fully integrated battery with 630Wh (17Ah), powerful Shimano Steps E8000 drive unit, trail-optimised geometry and the latest technologies make our new Tygon one of its kind e-bike with ultimate riding characteristics and unique design.
Tygon 70 29" Specifications:
- Frame: Kellys e-Frame 29, Uni-Body Integrated Design, Drive Core, tapered HT, internal routing, 12x148mm Boost thru axle
- Frame size: M / L / XL
- e-unit drive: Shimano Steps E8000, 36V / battery Kellys Re-Charge Li-ion internal 630Wh / capacity 17.5Ah
- Fork: Rock Shox Revelation RC (29) Boost, 120mm, DebonAir / Motion Control RC / Maxle Stealth 15mm thru axle
- Head parts: FSA 1.5 integrated
- Crankset: Shimano FC-E8000 (34) - length 170mm
- Shifters: Shimano SLX M7000 Rapidfire Plus / SW-E7000 switch for motor assist
- R/derailleur: Shimano Deore XT M8000 (direct mount)
- Speed: 11
- Cassette sprocket: Shimano CS-M7000-11 (11-46)
- Chain: KMC X11e (116 links)
- Brakes: Shimano SLX M7000 Hydraulic Disc
- Brake rotors: 180mm front / 180mm rear
- Brake levers: Shimano SLX BL-M7000
- Hubs: Novatec Disc (15x110mm / 12x148mm / 32 holes)
- Thru axle: Rock Shox Maxle Stealth 15x110mm front / Novatec 12x148mm rear
- Rims: KLS Valor 2 Disc 622x27 (32 holes)
- Spokes: Stainless steel black
- Tires: Schwalbe Hans Dampf Performance 60-622 (29x2.35) Tubeless Ready, Addix, folding
- Stem: KLS Active - diam 28.6mm / bar bore 31.8mm / 7° / length 60mm (M), 70mm (L - XL)
- Handlebar: KLS Active RiseBar - diam 31.8mm / rise 15mm / width 720mm (M - XL)
- Grips: KLS Poison
- Seat post: KS - Remote Telescopic - diam 30.9mm / length 485mm, travel 150mm
- Saddle: KLS Avenger
- Pedals: KLS Master
