Introducing the New Santa Cruz Stigmata

Introducing the New Santa Cruz Stigmata

Santa Cruz (United States) - Press Release: The road goes on forever and the party never ends.

When the Stigmata was resurrected in 2015, we fused a number of MTB standards and design features to create our spin on the modern CX bike. Something must have clicked, because within months of launch it raced to victory at the legendary Three Peaks, and has continued to contend at elite cyclocross races around the world.

Nowadays, the internally routed disc brakes, generous tire clearance and thru-axles approach that made the Stigmata famous have become more of a norm, so we took a fresh look at which standards the riders of tomorrow wanted access to today.

Threaded bottom brackets remain a perennial favourite across our entire line thanks to their proven robust, cost-effective and compatible design. “If it ain’t broke…” ...and it never is. Fender mounts add a bit of CYA, and highlight the Stigmata’s ever-widening scope of purpose. We added to that with three bottle cage mounts so that the frame can still hold at least one normal bottle even when running a front triangle bag.

Deeper adventures, bigger tires perhaps? The frame now clears up to a 45mm 700c or a 2.1” 650b tire. Marry the latter to our Force/X01 AXS mashup kit and you’ve got yourself the kind of drop-bar singletrack rallycat we can all get onboard with.

And when it comes to good old-fashioned off-road etiquette, the Stigmata’s had some coaching at the Highball school of stiffness, handling, and offroad feel. The carbon layup borrows knowledge gained from not just the Highball, but also Danny MacAskill’s trials bike, to produce a ride so law-abiding you’d think HR had sent it on a compliance training course.

Geometry plays a big part here too, so we’ve made tweaks to improve handling for smaller riders and reduce toe overlap. The reworking of the 52/54cm frames means the Stigmata now comfortably suits riders from 5’3” and up. Meanwhile different fork offsets—50mm for the 52-54cm sizes, and 45mm for the 56-61cm sizes—help ensure your little piggies don’t go to market on the front wheel.

Topped off with tidy details like 12mm front axle, flat mount brakes and build-specific Reserve wheel packages, the Stigmata is designed to let you decide whatever the heck you want this category to be.

Build Specs:

  • Kit: Red AXS Reserve
  • Price: $9899USD
  • Weight: 7.81kg / 17.22lbs
  • Wheel Size: 700c
  • Rear Derailleur: SRAM Red eTap AXS 12spd
  • Shifters: SRAM Red eTap AXS
  • Crankset: SRAM Red 1 46x33t - 170mm (52), 172.5mm (54-56), 175mm (58-60)
  • Cassette: SRAM Red XG1290 12spd 10-33t
  • Front Derailleur: SRAM Red eTap AXS Braze-on 12spd
  • Chain: SRAM Red 12spd
  • Bottom Bracket: SRAM DUB
  • Brakes: SRAM Red
  • Brake Rotors: SRAM CLX R Centerlock 160mm
  • Headset: Cane Creek 110 IS Integrated Headset
  • Bars: Easton EC70 AX flare bar
  • Stem: Easton EA90 Stem
  • Grips: Velo Bar Tape
  • Front Hub: I9 Torch 100x12 Centerlock 24h
  • Rear Hub: I9 Torch 12x142 XDR Centerlock 24h
  • Rims: Santa Cruz Reserve 22 700c Carbon Rims
  • Spokes: Sapim CX-Ray
  • Front Tire: Maxxis Rambler 700x40c
  • Rear Tire: Maxxis Rambler 700x40c
  • Tubes: Stans Sealant 2oz
  • Seat Post: Easton EC90 27.2 Zero Offset 350mm
  • Saddle: WTB Silverado Carbon Saddle


For more information about this article from Santa Cruz click here.
