Mondraker (Spain) - Press Release: Chrono Carbon is one of the most outstanding bikes in Mondraker 2019 range. A completely updated model featuring an all-new Stealth Carbon frame with the same geometry and design of our benchmark Podium Carbon and the best value.

The podium had no competition. Until now.

First step into XC racing; the new Chrono Carbon is born following the traces of the current Podium Carbon, preserving its high performance. With a frame weight of just 1.150 g, it takes advantage of our XC Forward Geometry concept, Stealth Carbon technology and FlatStays seat stays for the most compliant ride, giving the early XC-racer a bike with improved handling and stability.

The all-new Chrono Carbon offers unbeatable, ready-to-race XC performance in a lightweight package at the best value. The 2019 Mondraker Chrono features the same geometry as the high-end Podium Carbon wrapped in an all-new Stealth Carbon frame.

Technology:

Stealth Carbon:

Chrono Carbon R and Chrono Carbon introduce a new frameset with a sleeker design with thinner tubes with no edges and a flatter and more stylish top tube design with FlatStays seat stays of very low profile providing more speed and visual lightness with an more aggressive aesthetics with just 1.150 grams frameset weight.

Mondraker XC Advanced Geometry:

Following Podium Carbon geometry concept, 2019 Chrono Carbon has evolved towards a longer top tube length combined with 70,0º head angle and 73,5º seat angle and shorter chain stays (430mm) boosting traction with snappier handling and pedaling response. Moreover, Chrono Carbon feature new lightweight alloy stems with exclusive design and shorter sizing: (S-M: 60mm, L: 80mm, XL: 90mm) which increase the fun-factor and improve its handling at any riding condition.

Chrono Carbon R Specifications:

  • Frame: Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axel, Comfort Flat chainstays (Flatstays) design
  • Sizes: S: 395mm / M: 430mm / L: 470mm / XL: 520mm
  • Rear shock: /
  • Shock setting: /
  • Fork: RockShox SID RL 29, 100mm, DebonAir, tapered steerer tube, 15x110mm axel, 32mm alloy stanchions, offset 51mm. Settings: 2 position remote compression (open/lock), rebound, air preload
  • Headset: Onoff Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º
  • Stem: Mondraker, 6061 T6 Alloy, 31.8mm barbore, rise: -5º, length: sizes S/M: 60mm, size L: 80mm, size XL: 90mm
  • Handlebar: Onoff Notion 0.2, double butted 6061 alloy, rise: 4.8mm, width: 720mm, 9º backsweep, 0º upsweep, 31.8mm barbore
  • Grips: Onoff Diamond, 1lock-on, 130mm
  • Seatpost: Onoff Notion 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
  • Saddle: Mondraker Chrono Carbon R design
  • Front brake: Shimano MT501, RT56 160mm IS 6 bolts rotor, resin pads
  • Rear brake: Shimano MT501, RT56 160mm IS 6 bolts rotor, resin pads
  • Brake lever: Shimano MT501, servo wave, alloy lever
  • Rim: Mavic Crossmax 29, 25mm internal width, asymmetric, tubeless ready, 24 spokes
  • Spokes: Mavic Steel
  • Front hub: Mavic 15x110mm, sealed bearings, IS 6 bolts
  • Rear hub: Mavic 12x148mm, sealed bearings, ID360, IS 6 bolts
  • Front tyre: Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead
  • Rear tyre: Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead
  • Crank: Truvativ Stylo 7K Eagle, 12s, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm
  • Rings: 34T, CNC-machined alloy, X-SYNC 2
  • Bottom bracket: Sram DUB BSA, sealed bearings, 73mm
  • Pedals: /
  • Chain: Sram NX Eagle, 12s
  • Front  derailleur: /
  • Rear derailleur: Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
  • Lever: Sram Trigger NX Eagle, 12s, X-Actuation 1:1
  • Sprocket: Sram PG-1230, 11-50T, 12s
  • Hanger: Mondraker M068
  • Weight without pedals: 10,400



Other Models:

  • Chrono Carbon
